Water cooling camera HL-913HS is Special designed for high temperature environment security solution. Working Temperature: 1300°C
Furnace High Temperature Industrial CCTV Solution is used for Special high-temperature environments CCTV Solution. It can be widely used in steel Iron factory heating furnace, rotary kiln head, grate cooler, glass factory smelting furnace, etc.
The equipment can place the camera lens at the entrance of the furnace wall to observe the operation of the work piece in the furnace.
◆ This equipment adopts air cooling and water cooling methods.
◆ In order to reduce the radiated heat from the furnace to the equipment, a 1mm pinhole lens is used, which greatly reduces the radiation area.
◆ A double-layer protective cover is used to protect the lens. Circulating water is passed into the interlayer for cooling, and the lens is cooled by a line of gas. And blowing the cooling air out from the front end of the protective cover can suppress the flame in the kiln and block dust.
◆ The installation base plate is cooled by compressed air to protect the equipment from normal use for a long time.
◆ Work Temperature reach 1300°C
Model |
HS-913HS |
|
Main Feature |
(1) Furnace wall installation peek type (2) Lightweight design and easy maintenance (3) High temperature resistant pinhole zoom (4) Made of stainless steel, (5) Central control power outage, gas
|
|
Work Temperature |
Furnace temperature |
Q 1300 |
Control System |
Q 70 |
|
Exit device |
Automatic exit function |
Yes |
Manual function |
Yes |
|
Control device |
Alarm indication |
Automatic alarm for power outage, gas |
Two levels of control |
Can realize central control alarm and |
|
Power supply |
Voltage |
AC220V 10% |
Power supply frequency |
50Hz |
|
Air supply requirements |
Compressed air inlet pressure |
0.3 0.6MPa |
Compressed air inlet temperature |
Q 35 |
|
Compressed air minimum flow |
0.2 0.3M ³ /min |
|
Camera |
Resolution |
2.0MP 1080P |
WDR |
Support |
|
signal-to-noise ratio |
50db |
|
View angle |
Angle |
81 |
Circulating cooling water requirements |
Flow |
12M ³ /h |
Pressure |
0.2 0.4MPa |
|
Installation distance |
The maximum distance from the control |
