Starlight full color bullet camera/AX-F500WX-IP is Starlight Full Color HD 5.0MP water-proof outdoor ip camera.
Bullet IP camera /AX-F500WDB-IP main used in the hotel, supermarket, factory, chain stores, house
- ONVIF 2.4 ,5.0MP Waterproof bullet Camera
- 1944P 5.0megapixel, 1/1.8”5.0 Mpixel SonyIMX178 CMOS
- Resolution: (2592×1944@30fps)
- 1channel RJ 45
- 4 pcs array Led 2.8-12mm Varifocal lens 40-50m IR
- ICR Filter Auto switch, Motion Detection
- Full Color When View at night time and daytime.
- 1 channel Audio / Alarm /SD card
|
Camera |
|
|
Model |
AX-F500WX-IP |
|
Image Sensor |
1/1.8” 5.0 MpixelSony IMX178CMOS |
|
Picture Elements |
1944P 5.0MP, 2592(H)x1944(V) |
|
Minimum illumination (color ,B/W,IR ON) |
Color: 0.001Lux @ F1.2, B&W: 0.005Lux @ F1.2,0lux (IR ON) |
|
Interface |
Supports extended features of audio，Alarm, SD/TF card local storage,WIFI,4G optional |
|
Compatible |
Hikvision / XM etc brand CMS , and UC2 |
|
Electronic Shutter Speed |
1/10000s to 1/25s |
|
Auto control |
AWB/AGC/AE/AIC,4A |
|
White Balance |
Automatic |
|
Gain Control |
Automatic |
|
S/N Ratio |
≥ 39 dB |
|
BLC |
YES |
|
Lens |
|
|
Megapixel |
Yes |
|
Day/Night |
Yes( with IR CUT filter) |
|
Lens Type |
Varifocal Lens |
|
Focal Length |
2.8-12mm |
|
Maximum Aperture |
F/1.2 |
|
Mount |
CS |
|
Image Format |
1/2.7” |
|
Operation (Focus/Zoom/Iris) |
Manual/Manual/DC drive |
|
IR Led Quantity |
4 pcs array IR LED |
|
Max IR Distance |
40-50M |
|
Operation |
|
|
Storage |
Support multiple storage ,front-end storage |
|
Video Compression |
H.265MainProfile/H.264Mainprofile/M-JPEG |
|
Video Output |
1Vp-p Composite Output (75 Ohm, BNC) |
|
Video Streaming |
32Kbps-30Mbps Continuous adjustable support CBR/VBR,support Smart AVC/SCBR, To optimize the H.264 low stream |
|
Frame Rate |
30fps at 2592*1944 |
|
Video Resolution |
5.0MP The main stream：2592*1944，1-30 fps/s |
|
Audio |
G.711/AACCodec standard, |
|
Network |
|
|
Interface |
10/100M Ethernet |
|
Ethernet Protocol |
Support HTTP/RTSP/FTP/PPPOE/DHCP/DDNS/NTP/ONVIF/P2P |
|
Network Port |
10/100M Ethernet,anti-Lightning design |
|
General |
|
|
Environment Temperature |
0℃～50℃ |
|
Humidity |
20% to 80% RH (No condensation) |
|
Power Supply |
DC12V /POE 2.5W Max |
|
Weight |
2.3 kg |
|
Plastic Resistance |
IK10 |
|
Regulatory |
CE ROHS |
|
Web interface |
|
|
Installation Management |
Web-based Configuration |
|
Maintenance |
Firmware upgrade through software |
|
Applications |
|
|
Network Storage |
NVR, SERVER |
|
Smart Device Access |
HD Live for Windows Mobile、iPhone、iPad、Android |
|
Live viewing |
IE,mobile phone |
