- Support 32ch 1080Nunreal-time encoding;
- Support AHD, TVI, CVI,CVBS, IP videoinput;
- HDMI/VGA simultaneous video output;
- BIG 1U Case, 2 SATA(Up to 8TB);
- 1*10/100/1000Mbps auto-sensing Ethernet port, RJ45 port；
- Automatic networking support, a key to add equipment;
- Support the Onvif protocol;
- Support GB28181 (Optional);
- Cloud services, P2P, alarm information push to phone;
- Support remote access, support ARSP;
- Support DHCP, FTP, DNS, DDNS, NTP, UPNP, EMAIL,3G, WIFI, IP search, Alarm center, etc ;
- Mobile phone remote monitoring (iOS, Android);
- Multi browser access (IE, Chrome, Firefox, Safari);
- Support for more than twenty languages;
- Perfect protection circuit,unique triple watchdog function
- Support WEB, CMS, VMS, MYEYE Platform;
- Support 32ch 1080Nunreal-time encoding;
- Support AHD, TVI, CVI,CVBS, IP videoinput;
- HDMI/VGA simultaneous video output;
- BIG 1U Case, 2 SATA(Up to 8TB);
- 1*10/100/1000Mbps auto-sensing Ethernet port, RJ45 port；
- Automatic networking support, a key to add equipment;
- Support the Onvif protocol;
- Support GB28181 (Optional);
- Cloud services, P2P, alarm information push to phone;
- Support remote access, support ARSP;
- Support DHCP, FTP, DNS, DDNS, NTP, UPNP, EMAIL,3G, WIFI, IP search, Alarm center, etc ;
- Mobile phone remote monitoring (iOS, Android);
- Multi browser access (IE, Chrome, Firefox, Safari);
- Support for more than twenty languages;
- Perfect protection circuit,unique triple watchdog function
- Support WEB, CMS, VMS, MYEYE Platform;
|
|
Model |
AX-A5032N |
|
System |
processor |
Hi3531A |
|
Video |
Codec |
H.264 |
|
preview |
32*1080N (5 in 1) |
|
|
Encode |
32*1080N@15fps (5 in 1)； |
|
|
Decode |
8*1080N@15fps (5 in 1)； |
|
|
Multi-mode |
Analog:32*1080N@15fps (5 in 1) |
|
|
Hybird:8*1080N(analog)+8*960P(network) |
||
|
IP: 32*1080P;16*3M ;8*5M |
||
|
Playback |
16ch |
|
|
Audio |
Compression |
G.711a |
|
Intercom |
Support |
|
|
Management |
Record mode |
Manual>Alarm>Motion detection>Timing |
|
Inquire mode |
Inquire by Time/Calendar/Event/Channel |
|
|
Storage mode |
HDD Storage, Network Storage |
|
|
Backup |
Network, USB, SATA |
|
|
Interface |
Video input |
32*BNC（Support Coaxitron） |
|
HDMI output |
1*HDMI (MAX:1080P) |
|
|
VGA output |
1*VGA (MAX:1080P) |
|
|
Audio I/O |
16/1 |
|
|
Alarm I/O |
8/1 |
|
|
Ethernet port |
1*10/100/1000Mbps Ethernet port, RJ45 port |
|
|
PTZ control |
1*RS485, 1个RS232；Support for multiple PTZ protocol |
|
|
USB Port |
2*USB2.0 ports |
|
|
HDD |
2*SATA interface (Up to 8TB) |
|
|
General |
Temperature |
0 ℃ – + 55 ℃ |
|
Humidity |
10% -90% RH |
|
|
Power supply |
12V/4A |
|
|
Consumption |
<10W（Without HDD） |
|
|
Weight |
Around 3KG |
|
|
Dimension |
440mm(L)* 290mm(W)* 50mm(H) |
